The Salino Pressure Center is a high-efficiency hydraulic system that provides pressure boosting and energy recovery. The Salino Pressure Center combines four elements required in Reverse Osmosis (RO) process of seawater desalination: a high pressure pump, an electric drive, together with a booster pump and an energy recovery device. Where the KSB solution differs from other units is that it employs a single lubricant-free axial piston pump and single axial piston motor, the latter serving as an integrated energy recovery device. As a result, three of the elements are fulfi lled by one and the same unit: creating high pressure, compensating pressure losses and recovering energy. There is no need for a separate booster pump and the entire system runs on a single electric motor and frequency inverter. The electric drive has a rating of29 kW and all components are resistant to seawater and dimensioned with low life cycle costs in mind.Nike Zoom Kobe Shoes

Thumbnail (228 x 152 px):
Salino Press Center
Company:
KSB Shanghai Pump Co.,ltd
Innovation Awards:
2014 Ringier Technology Innovation Awards – Pumps & Valves
Is Award Product?:
